WEBINAR: Managing the Charge from Multihead Weigher to VFFS Machine

Emily Brogan

Hi, everyone. Thanks for tuning in to today's webinar on managing the charge from your multihead weigher to your vffs machine. My name is Emily Brogan. I'm the Marketing Manager for ROVEMA North America. And before we get started, I do want to go ahead and get a couple of housekeeping notes over with while folks are still joining us. We are recording this webinar and we will send you the access link in a follow up email on Monday. Please, if you want to submit a question, use the Q&A function at that bottom bar of your screen to submit any questions you may have. We'll get through as many as we can. If we don't address your question in person., we will get you the answer in an email early next week. So I have several panelists to introduce to you all that will be helping us as we unpack our topic today. First, I want to welcome Don Lawrence. He is the technical parts and warranty specialist with ROVEMA North America. Don, thanks again for pitching in on a second webinar with me now, Don, how long have you been with ROVEMA?

Don Lawrence

I have been with ROVEMA since 1989. And the first 28 years that I was with ROVEMA , I was in the service department traveling and installing and troubleshooting machines. And now I am in the office and technical parts and warranty specialist.

Emily Brogan

Thanks, Don. Second, I'd like to introduce Carlos Richetta. He is the area manager with ROVEMA Latin America. Carlos, could you share a little bit of your background with ROVEMA as well?

Carlos Richetta

Hi, Emily, thank you for the invitation to the webinar. I've been working for ROVEMA since 2013. I started as a service technician. I traveled around Latin America for two years. And then I jumped to the sales team. And I am in charge of the southern region of Latin America. So Peru, Chile, Argentina, and other countries. So that's it.

Emily Brogan

Awesome. Thanks, Carlos. So last but not least, we have Kyle Lasecki on our call today who joins us from MULTIPOND America. Kyle, could you give us some of your background with MULTIPOND?

Kyle Lasecki

Thanks, Emily for having me here. I'm excited to talk about the various scale experiences with everyone today. I've been with MULTIPOND for just over 10 years. We're in Wisconsin, it's naturally cold up here. So I hope everyone is safe from the storms we've been having this past week. Like Don and Carlos. I also started in service for about two or three years and I moved into applications for five to six years, worked on various projects, R&D, even in I helped customers on site issues and installs as well. And for the last two years I've been sales manager.

Emily Brogan

Awesome. So it's obvious we have a lot of technical expertise on our call today. Before we really dive into some case studies and some best practices, let's travel the journey of your products. And we're gonna walk through the anatomy of these components. So just from a very top level, you're going to see the infeed conveyor coming from the processing equipment. So then that is going to drop the product into a vibratory crosshead feeder, which is going to keep that steady flow product coming into the top of the multi head weigher, which is feeding into the vertical bagger. So today, we're obviously just going to be focusing on the bottom two components. So let's take a deeper dive into the anatomy of these two specifically, just so that we're on the same pages, we're diving into specific issues. So Kyle, since you're our scale expert today, why don't you go ahead and walk us through the anatomy of this multihead weigher? Sure, thanks, Emily. Um, first of all, please note that this webinar is like is not a sales pitch or a fix-all to your particular issue, MULTIPOND and ROVEMA together, we're just here to freely express our personal experiences to some specific challenges and what it took to fix them right? We may cover some broader topics as well as details between the transition from the scale to bagger. So, small disclaimer, please take these instances as with a grain of salt, and correlate as much as you can with what we have to your specific solution.

Kyle Lasecki

So for an overall view of the scale, what you see here is a 14 head one liter scale, MULTIPOND makes them from 10 heads or up to 36 heads. The size of the scale is kind of dependant on many project aspects, the speed, accuracy, product characteristics, mixing, if we need to, head space, bulk density of the products, a whole slew of product characteristics. On the very top is the distribution cone. This is the number one spot, first spot to make contact with the scale. It's main purpose is the distribute products from the cone to the feed trays In my personal experience, this is one of the main focuses for all products for all customers to look at. Just like they say with you eating food is in what you put in your body is what you get out- is the same thing for the scale to. Focus on top of the scale, and the rest of the scale should follow. We make two styles for the cones- rotary vibratory, and there's an integrated pre weigher underneath the cone that controls the amount of product coming to the scale. From there, the cone vibrates to the feed trays, and their simple jobs to vibrate the product to the hoppers. It's all integrated with the scale and the settings inside the monitor. And the feed trays it drops into hoppers, MULTIPOND calls and pre feed and weigh hoppers. Some people are more familiar with calling them pool hoppers. The first hopper on the top is a pre feed that essentially just stages the product just holds it and wait for the weigher to do its work. The weigh hopper, the second one, is essentially the moneymaker of the scale. It's what weighes the product is what makes the combinations. After that, after the combinations are found and dropped, it goes through the shoots and funnel. And primarily This is our main focus today to talk about that transition point. How do we help with what to look for? How do we make different solutions for that? What else picture is a cabinet that's all our controls are are housed in here electronics power, communication boards. The scale is IP69 so it has sloped roof, sloped angles and seals. And then the very bottom is the timing hopper which holds the collected weight. We'll talk about that more in more detail in the slides to come.

Emily Brogan

Awesome. Thanks, Kyle. So Don, do you mind doing the same for this stripped down diagram of a bagger?

Don Lawrence

Not at all, thank you Emily. Um, what you're seeing here is: we have the transition funnel at the top of the forming set. This is what is catching the product that has been released from the scale and from that point on, it slides down the forming tube or the filling tube. Now you will at some point some people have a inner filling tube, which is where the product will actually slide down. It's in its own tube allowing air to escape as the product is being pushed through the forming set. Just below the forming or the transition funnel, you have the forming collar which takes the film from a flat roll of flat roll stock through a series of rollers to create a little bit of tension on the film, so that it will track properly on the forming collar, giving you a good controllable vertical seal. And we formed this into a round tube. And the vertical seal bar that you see there is sealing the round tube after we've formed it, sealing it together. So that we now have a round tube. And then below that is the jaws, which you have one set of Jaws, they have two purposes: the top of the jaws seal the bottom seal of the bag, the bottom of the jaws seal the top seal of the previous bag. Once the jaws have touched or as soon as the jaws touch, that's when we want impact of the product that is coming through the forming or the transition funnel. And once the product impacts with the jaws, as soon as the jaws close, that gives us a maximum amount of settle time for the product to completely settle on top of the jaws before the jaws open up and release all of the weight of the product onto the hot seal. So that we don't separate the seal, the jaws are supporting the weight of the product. We also at the lower end of this we begin to open up the jaws very slowly to have a controlled release of the weight on the Hot seal. And at the same time, we're forcing air cold air in there to cool and cure that hot seal back to a solid state. At the same time the knife has cut and separated the two bags so that the previous bag will now drop onto an exit conveyor. And then the next bag will be transported down between the jaws. And we repeat this cycle over again. That pretty much what you wanted?

Emily Brogan

Yep. Thanks, Don. Yeah, so just to give everyone some context. For folks that aren't hands on with this equipment, it's often assumed that the biggest driver of production speed is how fast a vffs machine seal jaws can cycle sealing each package like you just described Don. But I know for a fact that 75% of the people that are listening on this call today are shaking their head because Sure, overall production speed it does top out for each machine when you're running like the dream product. But this is reality and your customers, they want the fluffiest popcorn, they want the stickiest sugar coated candies, they want every bean of their coffee to be perfectly whole when they open up that package. So when we talk about high speed, those less than ideal products, they have tendencies and those tendencies often become speed bumps. So today, our experts are gonna dive into some of the most common tendencies, and then we're gonna pair them with best practices. And we're gonna open up the q&a feature so that we can help more of you out with additional issues. So first of all, Carlos, when we were discussing this topic that you brought up, you brought up a recent story about the issue of running different package sizes and weights. And let me just go ahead and get this slide up. You know, flexibility in packaging machinery, it's imperative. So walk us through that story that you told us and then let's unpack some solutions around setting yourself up for success in this category.

Carlos Richetta

That's right, Emily. As you already mentioned, a lot of requirements the customers have for the product that they're purchasing, but we also have to think about what are the requirements of the factory in terms of flexibility. Flexibility, as you mentioned, is very important. And we want to take advantage of the of the equipment we purchase to make it a priority for all the range of products that we want to sell. And it happens. A couple years ago a customer bought a multihead weigher and vertical form/fill/seal machine from us, and they wanted to pack marshmallows- a very fluffly lightweight product and with very different weight ranges, so 30 grams and 200 grams with the same machine, same weigher. And you have to be very careful in these occasions because if you talk to the to the two vendors, to the multihead weigher vendor and the vertical form fill seal vendor, they will see their their own perspective of the product, and you somehow you have to make them work together. For example, if you have 30 grams of marshmallows, there are only six pieces, five to six pieces of marshmallow. And if you buy a multihead weigher that that needs to allow you to pack 30 grams and also 200 grams, the requirements are very different. And unless you want to pack 200 gram you end up with a huge multihead weigher with a huge timing hopper that's probably 200 millimeters wide. And this, this six or five or six pieces of of marshmallows when you're packaging 30 grams, they spread out in this 200 millimeters of timing hopper and then you have to direct all that product in a 70 millimeter forming tube. And that is very difficult to do. As soon as you release the charge, the products start jumping in the sides of the timing hopper and it takes forever till you get the product in the bottom of the pack. And you have the danger, you have the risk to end up with a perfect vertical form/fill/seal machine that can run 120 bags per minute, a perfect multihead weigher that can also 120 bucks per minute, but altogether you won't even reach 60. So the way this transition is planned between the multihead weigher and the vertical form fill and seal machine is very important. And you have to be completely transparent with both vendors of what you intend to do and how you intend to do to find the best solution.

Emily Brogan

So I know when we were talking about this, in preparation for this call, you did pose you know it's tough. But if folks want to run a variety of package weights there are there is there are some capabilities that give you that flexibility. Right? And that might be a question, some for Kyle as well. What are some solutions?

Kyle Lasecki

From MULTIPOND's perspective, we always try to get as much information as much as possible. No details should should be left behind. But even knowing the forming tube diameter beforehand helps us greatly because we can design the timing hoppers to have smaller diameters for the product based on the target weight. It makes a much easier transition if we have the whole collection together and not touching the sides of the forming tube as it's traveling down to the bagger. Right.

Emily Brogan

Right. Cool. So thanks, Carlos. Another big topic around products that need to be dosed with a scale is maintaining product integrity. So Kyle, can you walk us through some examples of best practices for managing the charges of fragile products?

Kyle Lasecki

Yeah, for sure, Emily, thanks. Brittle and/or fragile products are complicated to pinpoint because the same solutions for one customer may be completely different for somebody else. Some examples are baked items, they're easy to distinguish if you broke them like chips, crackers or cookies, but also like chocolate covered yogurt raisins, you know, we're not gonna want to put impressions in them. Sugar confectionery, we want to make sure that the sugar stays on the gummies and we're not tumbling them too hard. Or taking away the sugar before it gets to the product jars. Cube products like cheese or formed granola bars. We don't want to dent the corners as they fall. And last but not least, last but not least is the peeled apples or grapes. For those who aren't familiar if you damage sliced grapes or peeled grapes, they turns transparent and then a couple days later, they turn brown. MULTIPOND obviously tries to be transparent and handling these. We don't want to damage them at all but the operation The scale is to break out the flow of product, weigh them, and then put everything back together. So there's some inherent drop points in some few areas of attention that you may need to look at. Some of the drop points. Number one is the conveyor to the bulk feeder or to the scale. This is probably one of the largest drops. Besides the funnel that's inside the scale. Some remedies that we've thought of is that there's a slide that we can put in between to help the transition from one to the other. Another that we've used before is to drop some of the products on top of themselves, especially grapes, um, helps drop the height drop a little bit smaller, and it kind of gives a little cushion as it gets to the top. Another thing to consider is the size of the scale. Obviously, the bigger the scale, the more accuracy, the higher the speeds, you're gonna have output. For delicate products, we want to kind of Reel that in a little bit bigger the scale the wider the funnel that you're going to have. So with a less wide funnel, you can decrease your height. And it helps kind of collect things together. MULTIPOND designs as low as 10 head scales all the way up to. So if you're considering like 20 head, we can have you maybe possibly look at a 16 head to help with that. That final height. Number three is the funnel to transfer from the scale to the bagger. It's always that gray area. When the scale drops it is it now the scales or the bagger that needs to fix the problems. MULTIPOND likes to take care of those on front. One of them being is reducing the angle of the funnel, it helps reduce the product velocity and it helps less tumbling of certain products like cookies and crackers or, or, or grapes. MULTIPOND also adds a impact reserver on the inside of the funnel, kind of looks like a small little squid, we can dangle rubber or stainless little fingers down and it kind of gently braces the product before impact to the bottom. Last, but at least for the MULTIPOND's perspective is that we can add a timing hopper. There's another slide later on. I'll talk more about this. But it offers a great midpoint between the scale and the bagger. It reduces the drop height. And it kind of defines the scale's role versus the bagger role because we will take responsibility of collecting things and then the passing to the bagger during operation. My biggest example that I can give is we did our recent project with keto cookies, and keto cookies, they taste great, but there's no sugar or syrup acting as a glue agent and they are very brittle. Some of the things that we did is we reduced all the drop heights within three inches to the scale. We quoted a 16 head scale with a 45 degree funnel. It was large enough to get accessibility for cleanability. And then small enough to make sure everything slides in gently. Of course, we had impact reservers and then we had a timing hopper that opened with only one side of the flap that would open and close. And that helped slide and guide the cookies into the bagger.

Emily Brogan

Cool. Thanks, Kyle. Go ahead, Carlos!

Carlos Richetta

I would like to add that from the vertical form fill seal machine perspective, there are also measures that you can take to to handle this delicate products, of course, as Don will probably mention is the use of a continuous motion machine also makes the impact at the jars smaller. So the impact of the velocity, the difference in velocity between the jaws, and the cookies that are falling is reduced greatly. And you can also use inclined vertical form fill seal machines. At ROVEMA we even have an execution that you can you can adjust the inclination of the of the of the vertical form fill seal machine so that's also an alternative. Those are the main measures.

Emily Brogan

Thanks for giving us that alternative perspective, Carlos. I didn't want to gloss over that, so thank you, for reminding me. And thanks, Kyle. So for our next case, you can really run into issues running these especially when climate can be an issue. And cleanup especially can be a pain in the you know where, Don you brought up some great points around Best Practices when running sticky products. And when we all met together, you had an interesting story, can you catch us up on on the story that you told us about running sticky products.

Don Lawrence

I don't really remember which story, I probably told you a couple running sticky products is is very... it can be very challenging. The biggest thing running sticky products is number one. To keep your product in a nice, clean charge between each drop, we have to have a certain amount of space in between each one. But the timing of sticky product is very critical. On any machine. The timing of it is keeping the charge the leading edge of the charge in contact with the jaws as soon as they close gives you the maximum amount of settle time. And properly sizing, the forming set to the amount of product is crucial. Also, when you're utilizing these multihead scales. Sticky products are most likely going to be recommended to use a timing hopper where you can actually pre shape this charge to fit your forming set, or the inside diameter of your forming set. The more you touch a product, the more likely it is to slow down anytime your product touches your tube, and I believe Kyle mentioned this a moment ago, whenever you touch anything with this product, it slows it down. And also it strings it out. And it will also cause it to bounce from side to side and or swirl. So releasing the product into the transition funnel, which is guiding the product from the scale to the bagger. To the forming set. You don't want to have a lot of product, it is inherent to run around this round tube. And we call that swirl product swirl and or bounce when it bounces from side to side. Anytime you get any of this action, you're slowing the product down. And that's going to create two problems. Number one, if you can't control that, then the only option you have is to slow the machine down, which no one wants to do that. And number two, it's going to cause product in your seals. And when you get these sticky products such as candy or gummy products with sugar, and everything else, if you get one piece caught between your jaws, you lose two bags automatically. And then you contaminate the following bags because your jaws are now dirty. So keeping the product charges in a nice clean shape, keeping your timing perfect as or as perfect as you can get it utilizing your timing hoppers and everything. This speeds everything up. Cleaning your jaws is something that you have to actually stop the machine which means you're taking it out of production and clean your jaws we have products that are used specifically for cleaning chocolates or just not chocolates, but anything that is heavily sugared or any kind of sugar at all. We have products for that assist in cleaning your jaws from this material, utilizing a brass brush and then you have to clean your knife slot with a plastic device to keep from damaging your jaws. So anytime you have to do this, it's taking you out of production. And it's costing you time. So although we have developed cleaning methods and these cleaning products and stuff like that, it's still cost your time. production time, right. So we want to keep these products as closely timed as possible. Which means in the beginning it's like Kyle was saying the customer needs to make sure that they're explaining characteristics, to us and to the or to all parties involved in the project. If you have a product that's very difficult to handle, we need to know about this in the beginning and be very transparent about it. So that we can, there's so many ways of attacking a specific product issue. That, I mean, we could talk for days, about sticky and gummy products. Yep. And, but also, to come back around to what Carlos was saying about gentle handling of products. Yes, we do have machines, known as continuous motion machines, we have a lot of products that are coated with a hard shell candy on the outside chocolate on the inside these products, if they get fractured, if you fracture the outer coating of these products, it reduces the shelf life by half. So we have developed this continuous motion machine, which gives us the ability to have a non violent impact on top of the jaws when they close, and the product is being released from a scale, four feet six feet above us, they gain a lot of speed coming down through there. So with our jaws in a downward motion, it reduces the impact of that product. So high breakage, products, product stability, and it also gives us the ability to go faster with these products. But messy products are every product has its own characteristic. So right.

Emily Brogan

Thanks, Don, you're welcome. And I do want to point out, you know, Don, you mentioned, minimizing the contact of the product with the equipment so that you minimize the amount of sugar that can be knocked off or slid off or melted off or any of that, but then Kyle, for fragile products, you want to maximize that contact and soften the travel and, and slow it down if that is the best solution for your product. So that that's just a just an interesting parallel that I wanted to point

Don Lawrence

You have to weigh it out, you know, between speed and product protection. Yep. There's many, many variables involved in this.

Emily Brogan

One will oppose an alternative, another tendency that we'll have Carlos, I'm gonna bring it back to you. Product bridging can be a huge issue when it comes to high speed packaging of products like produce, which we have pictured here, or even baked goods like Kyle mentioned, sometimes like powdered donuts. Carlos, do you have some examples of maybe some additional products that have this tendency and some best practices around running these?

Carlos Richetta

Yes, yes, Emily. The picture you picked for this slide is perfect, because this is the shape of the product that sometimes gives you troubles with the with how the the charge behaves, enter into the vertical form fill seal machine. And as you mentioned, for fragile products, we want to maximize contact for sticky products, we want to minimize contact. For a high speed or some application, we want to keep all the product together in the charge of the product everything together and release it at one time. But for these kind of products, you sometimes need to separate products a little bit and do let it string out with a function that many, many multihead weighers have is a staggering charge or staggering charge. So the product is released with milliseconds of difference. So you get a string of product that will get into the forming to easier without custom bridging and without clogging the forming tube. This is a example that's very, very good one with a green beans. And in that is very, very useful. Also, sometimes, the products can produce this bridging, not entering the vertical form fill seal machine. But inside the bag, and the when this bridging occurs, the product takes up a lot of space inside a bag and sometimes the space that it takes is bigger than the volume of the bag itself. So you end up with products between the jaws, which is something you want to avoid at all costs. And we can use additional functions for this, there is a way that you can produce a bulge in the bag before the products enters into into the bag. And that increased the volume, the volume of the bag before the product enters in the bag. And even when there is some bridging, as the bag has more more volume, the product will will arrange itself in a better way, and will allow you to run either shorter bags, bigger speeds or, or without any interruptions in the in the in the process.

Emily Brogan

Awesome. Well, thank you, Carlos. So for our last case study topic, and Kyle, you kind of brought us to our proverbial table. Tell me about your recent experience with a customer was trying to evaluate if a timing Hopper was necessary for their products? What's kind of the criteria they would use to evaluate this? And can you also dive into the role that the component plays? We've touched on it some but I think that the way you described it was really cool when we talked about it before.

Kyle Lasecki

Yeah. Thanks Emily. To be completely truthful, in 10 years is probably the first time I've talked to talked about the timing hopper in the operation in detail because 95% of our applications included timing hopper. And it's kind of like a standard like, that's what the MULTIPOND does. There's some outlying circumstances, just like Carlos said, where you need to stagger it and have it, you're forcing it to line up. Sometimes we are being really slow, and we're doing like CBD type things where accuracy is much more important than speed. Or sometimes we're putting gummies in the bottle where you don't need to have a time hopper. Majority speaking, a timing hopper is very important. Without it, there'd be a lot more issues swirling as Don said, like we see with round products, or, or maybe grapes, sometimes we see products that bounce a lot and take a lot of cycle time. Like square like cube cheese, product separation, when we deal with small, smaller granular products, they become spread out. So that that charges between each other for the bagger to close the jaws, we're wasting their time to getting together. So timing hopper helps control the product at all times. And that's kind of the main purpose of the timing hopper is to not guess where the product is, and where it ends, just keeping everything together. Try to drop it all at one time try to limit how much wasted time between one shot together increase the cycle speed. I know the baggers appreciate because now they have clean seals. But then for us to increase speed is that we can actually drop multiple dispenses midflight. So there's one going down the funnel. So it could be another one in the timing Hopper, there could be another one down the funnel. So where I'm trying to go with this is that timing hoppers kind of help that separation between one bag to the next and then limiting your downtime. Overall. Timing hopper is also great because it eliminates the gray area between one equipment to the other. MULTIPOND we'll take responsibility all the way down and deposit and then we know that baggers responsibility is to make the bags to do their part. So without it products will fly all over the place, it swirls and everyone's kind of got a finger pointing who's going to fix it. Who does what, how can we get a better? Timing hopper draws that line in the sand saying Alright, we're getting good products we dropping it, everyone's happy. As I mentioned before, the timing hopper acts like an intermediate safe point. Instead of dropping 10 feet in the air , now we're limiting it right above the bagger inlet which is going to be four feet three feet. Again, it helps with limiting that chance of errors that we can't see as swirling the staggering all that kind of good stuff. operation is very, very simple. From our perspective, scale runs the power, there's no air included. And the timing is customizable right to the HMI of the scale. In the last 10 years MULTIPOND has advanced this timing hopper. Typically normally, you'd see like a standard duckbill or a two door opening, we make them into designs with the duckbill, which allows the product to be pointing down and helping get the product as soon as possible to the bagger kind of keeps everything intact and make sure not touching the forming tube. We also make a clamshell design that's more popular for larger applications for for large bags, large target weights. The picture you see on the screen is more of our our newer design, it's an alternating swiveling timing hopper. With this technology, we can go up to 180 to 200 bags a minute. And how it works is that one side is filling collecting and the other side is dispensing. So it kind of does everything I've talked before about collecting everything, put them together, dropping them, except now we're doing it in a alternative rotation manner. This one's especially very unique, it the flaps open sideways. And in reference to the motion of the timing hopper. Something we designed in the last year that goes up to 200 210 bags a minute. Something else I want to point out, we talked about timing hoppers, we talked about the timing. Something else we want to talk about is there's other solutions that we can offer look at for everyone to look at, is maybe having a plate on the inside of the funnel on the scale, which helps take up the volume because that scale can get very large. My biggest example is gum, cube gum, where it bounces from side to side or on the funnel, MULTIPOND had a hard time. And a very simple solution was to add a small back like a backward and it takes up that time for that stuff to settle. So taking things small, having simple solutions, timing hopper, impact preserver all kind of helps that cycle speed.

Emily Brogan

Cool. And I wanted to interrupt too with a question that popped up that seemed really relevant. Do you think that this would help make sure that product has time to settle and that it kind of helps to mitigate dust?

Kyle Lasecki

Yeah. So from a scale perspective, we everything wants to collect together, so we wait for that last bit of piece of dust. We, in our world, we call it a dump time, it's pretty much what gravity takes from the product to get from the weigh hopper to the timing hopper. Some products are different. So for running candies, they race to get there really fast, where if we're running chips or cheese, it takes a little bit more time. But in my experience, the best thing we can do is have a high speed camera. And then we run it and then we see what that that dump time takes to get from one point to the time hopper.

Emily Brogan

Cool. Yeah, so just a book in the segment of today's presentation. Before we dive into some more questions, we do want to leave you with some parting recommendations. The first is, you know, if you're gonna go through the process of building out a packaging solution, and you're using components from different suppliers, the most important thing that you can do that you should be doing is including them on any engineering discussions, and also having them talk to each other to spec out the best solution for your products. Obviously, Kyle is no stranger to the ROVEMA folks when a scale is required for a packaging solution. So team, what are some other final takeaways that you want to throw out to the group, maybe some hacks on how to troubleshoot some of these issues? Just throw them out there!

Kyle Lasecki

I mean, I'll go first. I know transparency. That's always the big thing from small details either. I always like to take things simply solve one solution before trying to solve the whole thing. Cookie breakage. Focus on the top of the scale. See how you can stop breakage there first, and then kind of do a waterfall effect. Keep working your way down. Try not to work on the biggest issue first try to do the small stuff and work your way to the hardest stuff.

Don Lawrence

I have something that I forgot to mention earlier is there's they're like we were saying they're different things, you know, but the best way to see what your product is actually doing. At the end, when it's actually filling the bag, you have a couple of ways of doing this. And it's just a little trick. Number one, you can put clear film on your machine, where you can see how your product is reacting as it comes out of the forming set. At that point, it's in a freefall stage, nothing else is going to touch it, but the bag. So to see how your product is landing on the jaws, how it's coming through the forming set, if it's being strung out, or if it's bouncing or swirling, or if you have late pieces falling clear film is the number one choice. But if you don't have clear film, that is the right size and the right makeup to run this bag or to run on the bagger. You can also take a drop light or a trouble light and place it on the faceplate of the machine behind your jaws just above your jaws and allow the light to shine through. And you can see the shadow of your products falling down through there. And you'll see if there's late pieces of charges arriving nice and clean. It's being strung out you can see the same thing. So that's just one little trick that you can use to see what your products actually doing, how it's behaving.

Carlos Richetta

I'll go next, as Emily mentioned, and Kyle also, share all the information you can about the product. There's one particular data that is always missing is the is the density of the product. And I believe that some project engineers don't understand how important it is for the weigher, and also for the bagger. And also for the format definition. Because you may have a machine that's running 40 parts per minute now, and you want to increase the speed to 100 bags per minute, the amount of products that you want that you are putting in a bag at 40 bags per minute, it's not possible that 100 bags per minute and you have to do some adjustment in the in the volume of the bag to have the appropriate headspace and sometimes there are small tricks that you can do. Small forming widths, forming sets that are very narrow are always more difficult from for the product to settle. It's always more difficult to to get all the product inside the forming set as well with this very narrow forming tubes. So if there is no objection from the marketing team, you can probably work with this a little bit and increase the speed and increase the performance. And at the end of the day, you will get a better return of your investment because the machine will be able to produce, to have a better throughput. And that's something that we are looking for.

Emily Brogan

Cool. Does anybody else have any pointers?

Don Lawrence

Other than, you know, we realize what a high stress industry that we're in with food packaging, you stopped for a minute you've cost 1000s of dollars, you've lost so much money in production. So we understand how stressful it can be. That's why we're here today is to help. And not just today, but anytime. Anybody can call us at any time with any type of questions. We're always here.

Emily Brogan

For sure. So we do have a couple of questions from Jeffrey and I think that he is really just wanting to understand how to evaluate the distance from the the filling agent to the jaw set particularly for small format packages. Is there kind of a rule of thumb?

Don Lawrence

We have a limit and it's the transport belts that really limit us. Our transport belts are made for pillow bag and or a flat bottom bag but we have to stop at the bottom of the forming tube at the middle of the bottom pulleys on the belt, because at that point, we go from pulling the film down the tube to pushing the film at that point. So if we have film that fits tight around the forming tube, it's really hard. It's kind of like pushing a thread, or a string or a rope, you know. So when you extend that tube past that point where we stop pulling and start pushing the film, you run the risk of the film bunching up. At the bottom of the belts, it's the film is still on the tube, but it affects your bag length. And it also can cause you product between the seals, and things like this. Now when we run a flat bottom bag, our tubes are much closer to the apex of our jaws, where the jaws come together, we have four to five millimeters, we actually turn our transport belts over, so that the belts are down close very close to the bottom of that forming tube. And we're only pushing the film can 15 millimeters. And then again, this also comes into effect where we can utilize what Carlos was talking about earlier, which is the bulging factor. He was talking about bulging the bag out. And at this point, at that point, if the film is bunching up, we can actually turn that around and actually have the jaws pulling the film off of the bottom of the tube while the belts are turning and transporting the bag. So there are things that we can do. But that's our normal standard of operations with forming sets. When we size the forming set. We size it to the bottom of the pulling section. Cool.

Emily Brogan

Cool, so we are a little over a time limit. If you did take the time to submit a question again, look out for a response to your answer in a follow up email. Jeffrey, I know that you said you've got some more questions that will be coming. So we're looking forward to catching up one on one on that. I do want to just thank you, gentlemen, for joining us and giving us some great insights from you know your drastically different perspectives on the packaging industry. And I do want to personally thank all of our attendees for listening in today on our webinar. I hope everybody enjoys the weekend and it is safe and toasty. We will see everyone on our next webinar.

Carlos Richetta

Thanks, Emily

Don Lawrence

Thanks, everyone for joining us.

Kyle Lasecki

Appreciate that. Thanks, everybody.
