Experience with Over 8,000+ machines Globally - With installations for your industry & product

Every product is different. Some clump while others weigh and fill easily. Others have particularly challenging merchandising and shelf-life requirements. And some are really pretty easy for any vertical bagger...until consistent high-speed output and up time become critical.

As machine builders we love to brag about all the details we obsess over - but the sealed bearings we use are no more important to your specific application than the size of drives and availability of Rockwell Allen Bradley PLCs.

Your product is your focus - it should be your machine builder's too!

And we've almost certainly worked with it before. Click on any of these common products/industries for insight into our expertise.

Our goal is to be an industry resource that you can turn to for insights on how to make vertical bagging the most efficient, highest return part of your manufacturing operation besides the product itself. Go ahead - contact us and test us on this!



Click on a product for more info

vertical form fill seal (vffs) for coffee

Rovema V/F/F/S solutions for Coffee Roasters

The art and science of a great coffee business don't end with the roasting cycle - both food service and retail markets are increasingly demanding of functional and merchandising features that Rovema routinely builds into machines.

  • auger filler and bagger from a single source - designed, manufactured and tested under the same roof, not just a common master brand
  • integrated auger and bagger controls
  • consistent head pressure in auger for repeatable and accurate package weights with the Rovema horizontal feed screw
  • AromaPerm(tm) Gas Flush to reduce residual O2 levels to  than 1% and reliable hermetic seals to keep it there with extended shelf-life

Commercial / Institutional Food Service is growing rapidly as more roasters shift capacity from fickle retail markets to high volume branded, co-packed and private label packaging of urn size and fractional packs. Much more than simple pillow bags, this business segment requires high speed, consistent accuracy of weight and reliable hermetic seals. Need a degassing coupon valve? Our single source approach extends beyond the augur and bagger to include our own proven integrated solution.

Retail demands all the same performance criteria AND aesthetics & convenience. Tin tie reclosable and Peel seal capability are typical options on our SBS system for both ground and whole bean coffee. And marketers love the full billboard they get on the package back with our Stabilo bag which incorporates an optional true offset vertical seal. As with food service packages, Rovema offers a proven degassing solution for integrated button valve placement on retail packs as well.

Accurately weighed and hermetically sealed in the bag, your coffee can transfer seamlessly to our range of secondary packaging solutions including tray and case packing.

Find out why many of the world's leading coffee manufacturers like Goodson Brothers and Euro Coffee (and others whose names you know well but which we're not allowed to share) have selected Rovema for packaging to cover the no mans land between roasting and brewing.

Read coffee articles
Watch our Coffee Webinar: Coffee Packaging After the K-Cup
Find all coffee related info

vertical form fill seal (vffs) for pasta

Rovema V/F/F/S solutions for Short Pasta Packaging

Rovema has been packaging pasta for over 50 years. In fact, the first ROVEMA machine was packaging spaghetti in a flexible film. Over the years pasta has been packaged in many type of packaging styles from pillow bags, to traditional direct carton filling to more premium styles in flat bottom style bags with the gable top folded or clipped.

Filling

Depending on the style of pasta, it is generally filled by cup feeder or scale. For pasta that is uniform in size such as elbows, ROVEMA can offer our VDD cup filler for a low cost and efficient dosing. The cup filler can be mounted over a ROVEMA bagger or a ROVEMA vertical
cartoner for a compact and small footprint. This solution offers a single control platform via the HMI. A scale can also be used for other products that tend to nest or have unique shape. In this case we work with a variety of scale manufactures to offer a turn-key solution.

Bagging

There are many different package styles Rovema can offer with our family of continuous motion Vertical Form, Fill, Seal Machines from simple pillow style bags to flat bottom style bags with a shelf ready appearance. Continuous motion is offered for pasta for gentle product handling and increased output. For a more premium look ROVEMA offers the SBS Brick pack machine. Some of the premium styles are flat bottom style bags flat bottom style bags with the top clipped
and fanned, top folded and held with reclosable tape or tin-tie and many more…

Cartoning

ROVEMA can offer a traditional bag and box line with a horizontal cartoner or a vertical cartoner, CMV, which offers direct fill into a carton or bag and box. In conjunction with our cup feeders, and baggers this is a winning turn-key solution with one control platform.

Case Packing

In addition to filling and bag making, Rovema manufactures secondary automatic packaging machinery. We can deliver a complete automatic turnkey packaging line for dosing, bag making, coding, inspection, cartoning and casing. The turnkey solution is engineering and built in one facility with a common workforce. This minimizes complication and risk for the turnkey solution.

ROVEMA’s equipment offers High levels of OEE and are achieved due to build quality and resulting machine performance, our experience and engineering to ensure proper execution of machines, common manufacture and workforce for your application. Our sales team will be ready assist you in finding your ideal packaging solution for pasta.

Read pasta articles
Find all pasta related info

vertical form fill seal (vffs) for powders

Rovema V/F/F/S solutions for Powder Products

  • 40% of all applications are in powders. Experience with a range of products - from copier toner to coffee. High application knowledge in powders.
  • Auger filler and Vertical Bagger from single source- eliminate potential finger pointing at FAT or issues after installation. Can purchase bagger and auger with complete confidence.
  • Auger tooling built in-house by Rovema. Not outsourced like most others. Special design tooling available for the most difficult products and applications. Auger is designed to reduce product degradation. The auger itself is milled from single piece stainless steel with no welds for high fill accuracies and less product giveaway.
  • Clam shell closure device available to prevent difficult free flowing products from getting into the bag seals.
  • Servo driven auger for precision and unsurpassed accuracy and reliability. (Servo controlled revolution of auger which provides positioning accuracy of auger of+/- 0.05%)
  • Two (2) models- SD-81 & SD-150. Which fill from 1 oz. to over 10lb.
  • Multicomponent fills are no problem in a combination Rovema Cup filler.
  • Auger comes standard with checkweigher feedback feature for optional downstream checkweigher.
  • Hopper level control is standard.
  • Low profile split door auger for easy maintenance, cleaning, and changeovers. Includes window for visual confirmation of product in hopper as a standard feature.
  • Height adjustment for auger screw is a standard feature - minimum product drop resulting in less dust contamination and reduced product in seals.
  • Tool-less change over for auger tooling is standard.
  • Economical solution with SD auger (cast aluminum hopper) or SDH auger (sanitary design with the hopper Available in 304 or 316 stainless steel, 3A dairy compliant-single piece hopper.) The SDH design is commonly found in milk powder applications.
  • Optional horizontal feed screw available to ensure product and head pressure level in the hopper remain constant for superior fill accuracy.
  • No upcharge for both auger and bagger controls integrated into single HMI. Hardware housed in single electrical cabinet. Simple operation and clean design with electrical cabinet and single power drop.
  • Special vacuum auger available for extracting air out of product resulting in product compacting (less volume and shorter bag equate to film savings), less dust, cleaner cutoff of product, and better fill accuracy.
  • Aroma Perm gas flushing option is a closed system delivering 1% or less residual O2 level. Originally designed for milk powder industry which has stringent gas flushing requirements.
  • Continuous motion bagger technology with powders. True “bottom up filling” creating less dust build up during filling, preventing dust in seals and stronger seal because of lower drop height. The longer fill window of the continuous motion design allows the end user to run the auger slower to obtain better weight accuracy and still maintain high speeds.


Read powder articles
Find all powder related info

vertical form fill seal (vffs) for candy

Rovema V/F/F/S solutions for Candy & Sweets Packaging

Rovema has over 50 years of experience packaging candy and an innovation leader. These can be packed into simple pillow bags or fancy stand up bags with special features. The solution can be a stand alone bagging machine or a complete automatic packaging line.

When it comes to fancy bags, the Stabilo® bag developed by Rovema in 1991 is an industry standard. Specific options include a true-offset seal which yields full panels on all 4 sides of the bag. Excellent for graphics. The true offset seal also aids in bag stand up since it reduces the multple layers in the bottom seal of a center back seal which can be troublesome in adhieving a stand up bag for smaller lighweight bags.

Other special bag styles include doy-style, Ropack, and Flexcan.

Factors to consider include product damage, fines, stickiness, bag opening size, reclosure among other things.

The new BVC series bag making technology provides advanced features that increase the performance and efficiency of automatic candy packaging. The BVC is a 2-axis servo driven machine capable of operating at speeds in excess of 240/min. Springs have been eliminated from the jaws meaning precise control over jaw position. This means excellent product in jaw detection even at the highest of rates which reduces product in seal and other quality control issues. Another feature of the BVC is Premium Seal ® which provides variable pressure over the course of once bag making cycle. This results in better performance in handling fragile films and overall better seal performance for challenging film structures. The BVC also is the first bag maker to uses servo gusseting which gives much higher performance when creating gusseted bags especially at higher speeds and with lighter gauge films. Refer to separate information here [link] for complete details on the BVC.

Machine versatility is key with a Rovema solution. This results in producing various bag styles on the same machine with efficient and repeatable changeover.

The SBS machine solution takes bag making to another level by delivering low fill drop heights, extreme flat bottom bags, and additional bag features such as tin tie, gather + clip, fold over and tape over 30 such bag top styles available.

Dosing is primarily accomplished with weigher or cup doser. The former generally gives greater accuracy and the latter greater speed. The right solution is determined by evaluating output versus giveaway cost along with the other considerations mentioned above.

With either dosing solution Rovema provides turnkey solution. We can offer direct mount weighers requiring no mezzanine (reduced clutter and better hygiene) and one common control panel for both weigher and bag maker.

For cup dosing solution, Rovema is the manufacter of both doser and bag maker providing a single source solution again integrated with direct mount and common (one) control panel interface.

Opening and reclosuer is a consideration. Bags can be produced with a simple tear notch for ease of opening. Zipper is common. There are various types including a velcro type. Other reclosures include tin-tie (less common), tape (dust is a concern).

In addition to dosing and bag making, Rovema manufactures secondary automatic packaging machinery. We often deliver complete automatic turnkey packaging lines for dosing, bag making, coding, inspection, cartoning and casing. The turnkey solution is engineered and built in one facility with a common workforce. This minimizes complication and risk for the tunkey solution.

Allen Bradley or Industrial PC based control - with either there are no proprietary control components. All OEM control components.

Highest levels of OEE are achieved due to build quality and resulting machine performance, experience and engineering to ensure propoer application and execution of machines, common manufacture and workforce.


Read candy articles
Find all candy related info

vertical form fill seal (vffs) for snacks

Rovema V/F/F/S solutions for Salted Snacks & Bakery Products

Rovema offers a number of solutions for your packaged Bakery and Snack needs. There are multiple continuous motion models Rovema can offer. The BVR 230 continuous motion bagger with fully integrated scale has been designed specifically for the Snack Industry. Additionally the BVK and BVC series continuous motion baggers are available to meet your needs. For lower output or basic pouch styles and sizes the intermittent BVI is offered. All Rovema models can be integrated with a Rovema filler, an existing filling system or a new filling system of your choice. Each application would be
reviewed with the filler supplier and designed and built to your specific needs and requests, then tested
and proved as needed to provide the best and most efficient stack-up.

  • Product supply provided to packaging
    • Best performance starts with a steady supply of product to the fillers, Be it Horizontal motion, vibratory or belts a steady and consistent supply of product is the beginnings the great performing line
  • Combinations Scale / Volumetric Filler
    • This is the Heart beat of Production. It sets the pace for rest of the packaging line to
      follow.
    • Select the best scale configuration for your product
      • High Speed (small bucket steep angled high speed chutes)
      • Medium Speed (larger buckets Standard Angled chutes)
      • Gentle Handling (Delicate fragile products)
    • Don’t forget best methods for handling stick products and address product build-up on
      the pans
    • High Speed timing Hoppers can be used for shaping charges and increasing speeds
    • Addressing dust and fines at the beginning helps the rest of the line perform better
  • Pick the Right Transitions
    • Small inlets funnels keep the charge from expanding out ward traveling from one transition to another and maintains falling speed
    • Steep angles keep the charge focused and minimized swirling
    • Integrated forming set / funnels minimize change parts and speed changeovers
    • Bias cut funnels increase speeds and minimize bridging
  • Choose the right forming set
    • Smooth, Dimpled Stainless Steel shoulders are options to choose from
    • There are various coating that can be applied to minimize sticking and extend shoulder wear
    • Epoxy shoulders can be an alternative
    • Integrated Funnel / Transition are options
    • Shoulder angles can be modified for special needs and difficult films
    • Round, Oval, Square and other shapes are available for those special needs
    • Snack tube / open back former are helpful with very small formers and bridging
    • Swing gates at the bottom of the forming tube can protecting films from sharp and hard
    • Product clamshells can be used for slowing product down
  • Rovema Leads Packaging Technology Innovation
    • Rovema understands each application and over 60 years of experience have guided us with the features we are known for. The following are just a few as Rovema continues to develop long term solutions for the packaging industry.
      • Options for Film unwind design to enhance film handling
      • Web tracking at the forming set for fast response
      • Self-centering Vacuum belt (No Need to adjust)
      • Swivel open Seal Jaws for safe cleaning of front and rear jaws and changing out cutting knife
      • Sense and Seal technology for sensing product in the jaws assuring quality bags released to downstream.
      • Servo Gusseting with size change memory
      • Hinged Electrical cabinet for increased machine access
      • Internal vacuum pump lower DB levels at machine
      • Customized discharge chutes for application
Read snack & bakery articles
Find all snack & backery related info
vertical form fill seal (vffs) for cereal

Rovema VFFS solutions for RTE Cereals

Providing a quality package and performance from your VFFS machine for Cereals requires more than just a quality VFFS machine. It requires knowledge and understanding of each of the RTE Cereals. RTE Cereals come in many Shapes, Sizes Textures and coatings. They often come with marshmallows, fruits and raisins and nuts of other types of ingredients mixed in. There is a high demand for high performance unit operations requiring minimal experience to operate and maintain both are a major goal of Rovema VFFS machines we work closely with the customers and suppliers integrating the upstream and downstream equipment to enhance the overall performance of the filler and bagger as unit operation.
  • Product supply provided to packaging
    • Best performance starts with a steady supply of product to the fillers, Be it Horizontal motion, vibratory or belts, a steady and consistent supply of product is the beginning of a great performing line
  • Combinations Scale / Volumetric Filler
    • This is the Heart beat of Production. It sets the pace for rest of the packaging line to
      follow.
    • Select the best scale configuration for your product
      • High Speed (small bucket steep angled high speed chutes)
      • Medium Speed (larger buckets Standard Angled chutes)
      • Gentle Handling (Delicate fragile products)
    • Don’t forget best methods for handling stick products and address product build-up on
      the pans
    • Addressing dust and fines at the beginning helps the rest of the line perform better
  • Pick the Right Transitions
    • Small inlets funnels keep the charge from expanding out ward traveling from one
      transition to another and maintains falling speed
    • Steep angles keep the charge focused and minimized swirling
    • Integrated forming set / funnels minimize change parts and speed changeovers
    • Bias cut funnels increase speeds and minimize bridging
  • Choose the right forming set
    • Smooth, Dimpled Stainless Steel shoulders are options to choose from
    • There are various coating that can be applied to extend shoulder wear
    • Epoxy shoulders can be an alternative
    • Integrated Funnel / Transition are options
    • Shoulder angles can be modified for special needs and difficult films
    • Round, Oval, Square and other shapes are available for those special needs
    • Snack tube / open back former are helpful with very small former and bridging
      problems
    • Swing gates at the bottom of the forming tube can protecting films from sharp and hard products are options
    • Product clam shells can be used for slowing product down
  • Rovema is a Technology Leader
    • Rovema understands of each application and past experiences have guided us with the
      features we are unknown for. The following are just a few as Rovema continues to
      develop long term solutions for the packaging industry.
      • Options for Film unwind design to enhance film handling
      • Web tracking at the forming set for fast response
      • Self-Centering Vacuum belt (No Need to adjust)
      • Swivel open Seal Jaws for safe cleaning of front and rear jaws and changing out
        cutting knife
      • Sense and Seal technology for sensing product in the jaws assuring quality bags released to downstream.
      • Servo Gusseting with size change memory
      • Hinged Electrical cabinet for increased machine access
      • Internal vacuum pump lower DB levels at machine
      • Customized discharge chutes for application
Read cereal articles
Find all cereal related info
vertical form fill seal (vffs) for spices

Rovema V/F/F/S solutions for Salt, Sugar & Spice Products

Rovema has been packaging spice for decades all over the world. The spice group is one of the most dynamic product group from Paprika, to pepper corns to bay leaves. Spice has been packaged in many type of packaging styles from pillow bags to more premium styles in flat bottom style bags with the gable top featuring a zipper reclosure or tin-tie. Spice is also
introduced with other products such as rice, and many other food items.

Filling

Due to the wide variety of Spice products, the items can be filled with many different methods. For powdery type spices, such as Paprika, it can be dosed with ROVEMA servo auger filler, model SD. For spice products that are more uniform in shape such as salt or pepper corns, the
spices can be filled by a cup feeder. Either one of ROVEMA’s VDD cup filler or SD auger filler are an efficient dosing solution. The both can be mounted over a ROVEMA bagger for a compact and small footprint. This solution offers a single control platform via the HMI. A scale can also be used for spice products such as bay leaves. In this case, we have established relationships with a variety of scale manufactures to offer a turn-key solution. In some cases, multiple fillers are used for a product mixture.

Bagging

There are many different package styles Rovema can offer with our family of Vertical Form, Fill, and Seal Machines from simple pillow style bags to flat bottom style bags with a shelf ready appearance. Typical vertical bag applications for rice can utilize a variety of films such as heat sealable laminates, or LDPE or films. Additional recloseable features can be offered such as a
zipper reclosure. An intermittent or continuous motion vertical bagger can be offered for spice applications depending on the application requirements. For customers that want to provide a premium bag and eliminate the glass or plastic jars, ROVEMA offers the SBS Brick pack machine. ROVEMA can provide flat bottom style bags with the gable top folded with a tin-tie or recloseable tape. This style will reduce your carbon footprint and reduce your overall packaging costs.

Cartoning

ROVEMA can offer a traditional bag and box line with a horizontal cartoner. In conjunction with our auger fillers, cup feeders, and baggers this is a winning turn-key solution with one control platform.

Case Packing

In addition to filling and bag making, Rovema manufactures secondary automatic packaging
machinery. We can deliver a complete automatic turnkey packaging line for dosing, bag making, coding, inspection, and casing. The turnkey solution is engineering and built in one facility with a common workforce. This minimizes complication and risk for the turnkey solution. Case styles can be offered from the RSC case, trays or tray and lid applications.

ROVEMA’s equipment offers high levels of OEE and are achieved due to build quality and resulting machine performance, our experience and engineering to ensure proper execution of machines, common manufacture and workforce for your application. Our sales team will be ready assist you in finding your ideal packaging solution for rice.

Read salt, sugar & spice related articles
Find all salt, sugar & spice related info

vertical form fill seal (vffs) for rice

Rovema V/F/F/S solutions for Rice Farmers

Rovema has been packaging rice for decades all over the world. Rice has been packaged in many type of packaging styles from pillow bags, boil in bag, to traditional bag-n-box lines, to more premium styles in flat bottom style bags with the gable top featuring a zipper reclosure or folded and taped.

Filling

Rice, it is generally filled by cup feeder or scale. ROVEMA’s VDD cup filler is a low cost and efficient dosing solution. The cup filler can be mounted over a ROVEMA bagger for a compact and small footprint. This solution offers a single control platform via the HMI. A scale can also be used. In this case we work with a variety of scale manufactures to offer a turn-key solution.

Bagging

There are many different package styles Rovema can offer with our family of Vertical Form, Fill, and Seal Machines from simple pillow style bags to flat bottom style bags with a shelf ready appearance. Typical vertical bag applications for rice can utilize a variety of films such as heat sealable laminates, LDPE or HDPE films. Additional recloseable features can be offered such as a zipper reclosure. A contiguous motion vertical bagger can be offered for rice applications to maximize output speeds. For boil in bag applications, ROVEMA can integrate a film perforation unit to perforate the film prior to filling. In addition we offer special jaw patterns for a “fork slot”. For customers that want to maximize shelf space or palletizing, ROVEMA offers the SBS Brick pack machine. ROVEMA can provide flat bottom style bags with the gable top trimmed just above the product level, leaving virtually no head space or a bag top that is folded and taped. The tape then can be used a reclosure feature. These package styles allow bags to be stacked on top of each other on the shelf and in the case.

Cartoning

ROVEMA can offer a traditional bag and box line with a horizontal cartoner. In conjunction with our cup feeders, and baggers this is a winning turn-key solution with one control platform.

Case Packing

In addition to filling and bag making, Rovema manufactures secondary automatic packaging
machinery. We can deliver a complete automatic turnkey packaging line for dosing, bag making, coding, inspection, and casing. The turnkey solution is engineering and built in one facility with a common workforce. This minimizes complication and risk for the turnkey solution. Case styles can be offered from the RSC case, trays or tray and lid applications.

ROVEMA’s equipment offers high levels of OEE and are achieved due to build quality and resulting machine performance, our experience and engineering to ensure proper execution of machines, common manufacture and workforce for your application. Our sales team will be ready assist you in finding your ideal packaging solution for rice.

Read rice articles
Find all rice related info
vertical form fill sea (vffs) l for baby formula

Rovema V/F/F/S solutions for Powdered Baby Formula

  • Sanitary design-Servo SDH auger Hopper available in 304 or 316 stainless steel, 3A dairy compliant-single piece hopper is also available. Surface roughness (finish) of product contact parts is Ra <0.8.
  • Optional horizontal feed screw available to ensure product and head pressure level in the hopper remain constant for superior fill accuracy of 1% or less.
  • Special vacuum auger available for extracting air out of product-,Less dust and a clean product
    cutoff between fills with minimum seal contamination at higher fill rates. Product compacting that may reduce film usage (cutoff length) per bag.
  • Designed specifically for milk powder, Rovema’s Aroma Perm Gas Flushing system can achieve
    1% or less residual O2 level.
  • Reduce project risk with both Bagger & auger from single source. Integrated solution from same
    manufacturer. Aftersales support from single source-no finger pointing.
  • Non-tubular, solid machine bagger frame available in stainless steel.
  • Excess hole in front plant with covers eliminated. Better sanitary design.
  • Electrical cabinet spaced out 30mm from frame for easy cleaning and better sanitary design.
  • Integrated zipper applicator for re-closure feature.
  • Unparalleled gas-tight seal strength and quality with Rovema’s premium seal technology. Guaranteed to meet the stringent seal quality requirements in milk powder packaging.
Read formula articles
Find all formula related info
vertical form fill seal (vffs) for frozen foods

Rovema V/F/F/S solutions for Frozen Food Producers

The Individually Quick Frozen (IQF) market has been exploding over the past 10 years offering new products and packaging styles in the freezer section at the local grocery stores. IQF products are packaged in many forms in today’s market. From the traditional LDPE pillow bags, and bag-n-box packages, to more premium styles in flat bottom style bags with a gable top featuring a zipper reclosure or multi-component meals. IQF covers a wide variety of products from frozen vegetables, ready-made meals, and meat.

Filling

Traditionally a scale is used to meter the product or products. ROVEMA has established relationships with a variety of scale manufactures to offer a turn-key solution.

Bagging

There are many different package styles Rovema can offer with our family of Vertical Form, Fill, and Seal Machines from simple pillow style bags to flat bottom style bags with a shelf ready appearance. Typical vertical bag applications for IQF can utilize a variety of films such as heat sealable laminates or LDPE films. Additional recloseable features can be offered such as a
zipper reclosure or tape reclosure for pillow or flat bottom style bags that have a shelf ready
appearance. An intermittent or continuous motion vertical bagger can be offered for IQF depending on the application requirements. ROVEMA offers a line of vertical baggers that features a stainless steel machine frame and wash down execution for wet environments.
Additionally, ROVEMA’s new construction on the BVC series is a solid frame for better hygiene and eliminates tubular construction. Finally, the BVC series has many 3A features and may be a fit for dairy and meat applications. The BVC-400 was specifically designed for the IQF market.

Cartoning

ROVEMA can offer a traditional bag and box line with a horizontal cartoner. In conjunction with our baggers this is a winning turn-key solution with one control platform built under a single roof.

Case Packing

In addition to filling and bag making, Rovema manufactures secondary automatic packaging machinery. We can deliver a complete automatic turnkey packaging line for dosing, bag making, coding, inspection, and casing. The turnkey solution is engineering and built in one facility with a common workforce. This minimizes complication and risk for the turnkey solution. Case styles can be offered from the RSC case, or tray and lid applications.

ROVEMA’s equipment offers high levels of OEE and are achieved due to build quality and resulting machine performance, our experience and engineering to ensure proper execution of machines, common manufacture and workforce for your application. Our sales team will be ready assist you in finding your ideal packaging solution for frozen food.

Read frozen food articles
Find all frozen food related info

Vertical form fill seal (vffs) for liquids

Rovema V/F/F/S solutions for Liquids, Sauces, Gels & Creams

  • Material savings over traditional #10 cans for food service processors.
  • Stainless steel, sanitary design to withstand the harshest environments. Sloped NEMA 4X rated electrical cabinet with rugged non-tubular machine frame. All contact parts executed in 316 Stainless steel. Sealed front and back plate to prevent water ingress in machine housing.
  • Easy machine access for maintenance, quick changeovers.
  • Stainless steel product catch tray with drain to keep film and machine free of debris.
  • Advanced continuous motion servo technology for cross seals. 2-Axis Servo Jaw Motion – Both the vertical and horizontal jaw motion are programmable through the HMI resulting in higher output speeds and more sealing flexibility. Highest outputs in its class.
  • Combination of proven technology (cross seal jaws- BVC & squeeze rollers -BVI)
    • Servo drive film feed belts for smooth film feeding and accurate bag length
  • Available in Allen Bradley controls with user friendly operator interface. Remote diagnostics available.
  • Power unwind unit for rolls up to 600mm diameter. (less film changeovers, lees downtime.)
  • Manual splice table to facilitate quick film changeovers.
    • Special design servo driven squeeze rollers to clean seal area prior to sealing (clean seals=strong seals), evacuate air, reduced headspace (reduced fill usage, consistent bag shape for easy case packing of frozen bags. Easier to freeze.), and accurately meter the product in bag for superior accuracy.
  • Single or two part fills. Can integrate will pump, combination scale, and bucket elevators.
  • Hot or cold fill up to 190F. viscous and non-viscous products with and without particulates. (Soups, sauces, dressing, condiments, macaroni & cheese.)
  • No film contracts required.
  • Bag widths up to 260mm, bag length up 600mm.
  • Customer supplied checkweigher system can be integrated for automatic checkweigher feedback for weight correction.
Read liquid articles
Find all liquid related info
vertical form fill seal (vffs) for nuts

Rovema V/F/F/S solutions for Nut Growers

Rovema has over 20 years of experience packaging nuts. These can be packed into simple pillow bags of fancy stand up bags with special features. The solution can be a stand alone bagging machine or a complete automatic packaging line.

When it comes to fancy bags, the Stabilo® bag developed by Rovema in 1991 is an industry standard.  Specific options include a true-offset seal which yields full panels on all 4 sides of the bag.  Excellent for graphics.  The true offset seal also aids in bag stand up since it reduces the multiple layers in the bottom seal of a center back seal which can be troublesome in achieving a stand up bag for smaller lightweight bags.

Factors to consider include breakage, fines, stickiness, bag opening size

The new BVC series bag making technology provides advanced features that increase the performance and efficiency of automatic nut packaging. The BVC is a 2-axis servo driven machine capable of operating at speeds in excess of 240/min.  Springs have been eliminated from the jaws meaning precise control over jaw position.  This means excellent product in jaw detection even at the highest of rates which reduces product in seal and other quality control issues. Another feature of the BVC is Premium Seal ® which provides variable pressure over the course of once bag making cycle.  This results in better performance in handling fragile films and overall better seal performance for challenging film structures.  The BVC also is the first bag maker to uses servo gusseting which gives much higher performance when creating gusseted bags especially at higher speeds and with lighter gauge films.  Refer to separate information here [link] for complete details on the BVC.

We run tube nuts which are particularly difficult due to the small bag opening. Over the past 5 years we have developed technology that has resulted in output increases of over 40%.

Dosing can be accomplished with weigher or cup doser. The former gives greater accuracy and the latter for greater speed. The right solution is determined by evaluating output versus giveaway cost.

With either dosing solution Rovema provides turnkey solution. We can offer direct mount weighers requiring no mezannine (reduced clutter and better hygiene) and one common control panel for both weigher and bag maker.

For cup dosing solution, Rovema is the manufacturer of both doser and bag maker providing a single source solution again integrated with direct mount and common (one) control panel interface.

Gas flushing is also a consideration where residual oxygen level is the primary factor.

Opening and reclosure is a consideration. Bags can be produced with a simple tear notch for ease of opening. Zipper is common. There are various types including a velcro type. Other reclosures include tin-tie (less common), tape (dust is a concern).

Read nut articles

Find all nut related info
