The cartoning machine with continuous mode of operation is designed to produce between 80 to 250 cartons per minute. A number of different modules ensure trouble-free operation.
In addition to a hygienic design with gull-wing doors for easy access and low ergonomic loading height of the blank magazine, the machine offers solidly constructed, functional subassemblies and adjustments. All internal components in contact with the product are made of stainless steel. At the customer’s request, the frame is also available in stainless steel.
A change of size is a quick operation that does not require tools and can be augmented with half or fully automatic adjustments. Packing of soft bags and stacks of bags is supported for the optional product conditioner and top confiner. These units also ensure smooth production when difficult products must be loaded.
The intermittently operating cartoning machine is designed to produce up to 85 cartons per minute. The machine's compact and simple construction ensures rapid size changes and simple operation.
To meet the hygienic design requirements, all internal components and components in contact with the product are made of stainless steel. At the customer’s request, the frame is also available in stainless steel. In the construction of CMH-I, the greatest attention was paid to the ergonomic loading height of blank magazines and that the functionally relevant components are of solid construction. The compact design ensures optimized accessibility that is most important for fast and easy setup of the machine. You only need to open a single door on the operator side to gain access to all components of the machine.
A change of size is a quick operation from the operator side and does not require tools. It can be augmented with half- or fully automatic adjustments. Packing of soft bags and stacks of bags is supported by the optional product conditioner and upper guide. These units also ensure smooth processing when difficult products must be loaded.
A special feature of the machine is box erectors, which can be used to erect left- or right-handed boxes. The mirrored installation of two machines with a central operator console no longer presents a problem. The forced opening of the box reduces faults when boxes are erected.
Dual insertion slots and automatic calculation of movement profiles for all drives ensure optimized slow movements. Thus, the machine operates smoothly and reliably.
The Rovema CMV series can be supplied with one or two integrated bag makers as a compact, flexible Bag in Box machine, optionally available with direct-filling facilities.
All this is available from a very compact machine.
This is probably the most compact Bag in Box line. In this case, one or two bag makers are integrated into a cartoning machine, and additional conveyors and/or transfer systems are not required.
Depending on the configuration and the application, up to 120 folding boxes may be produced per minute. The bags are transferred directly from the vertical bag maker into the vertical folding box. Folding boxes are transported through the machine with oscillating velocity so that the bag is transferred safely into the box.
In addition to the patented box erection and automatic size adjustments, the CMV offers further advantages in comparison with horizontal cartoners. This means that additional modules in the machine can compact the products to achieve a box fill ratio of 95%.
Ideal for compactable products such as tea or aerated powder.
The machine can safely pack up to 200 folding boxes per minute and is designed for the direct packing of freely flowing and slightly dusty material into boxes.
The frame of the machine is similar to the Bag in Box CMV, however, a continuous revolving filling module is located at the center of the machine.
The machine is designed in a line-type design, and it can be controlled completely from the front. The box erection, box transportation, different sealing modules and the filling module are clearly visible. In addition to the labyrinth folding system that is usually required for direct filling, the gluing system can be upgraded to a sift-proof system.
Simple size adjustments, a clear line of design and excellent machine control speak for themselves.
The flexibility of the CMV series, bag in box or direct filling ensures that you are properly prepared for future packing needs.
The compact machine concept enables the erecting, filling and closing of trays with inside or U-shaped lids, from flat blanks, in a minimum amount of space.
In combination with a grouping system, corresponding to the requirement of the sales packaging, a system solution specially adapted to the request of the customer is available.
The complete erecting, filling and closing process only takes place at two stations. Thus, usual interference sources are reduced to a minimum and the functional reliability increases considerably. The case blanks are held safely and precisely positioned in all stations througout the whole packaging process.
This optimum packaging process leads to geometrically exact packages. As product and packaging are treated carefully, the whole packaging process runs safely and in a controlled manner.
Flexible grouping systems — cycle chain or collecting conveyer for goods to feed into the case — enable different product orientation in the case.
High-efficiency/high-volume packaging situations may call for a more complete, integrated end-of-line solution. Rovema offers a variety of machines for cartoning, tray packing, lidding and case packing. Consistent with our approach to all equipment, these are designed, built and run out under the same roof and by the same company. There's often peace of mind for engineers, maintenance and procurement teams to buy packaging lines without another layer of integration complexity and potential finger pointing — even among divisions of the same global brand.
